Lenovo Offset 1Ton

Built around a 42U frame that supports a full 1000 kg, this Lenovo floor-standing cabinet is engineered for high-density server and networking deployments. The offset mounting rails open up extra depth for deep equipment, while the 70% open-area perforation on both front and rear doors keeps airflow moving through the heaviest thermal loads.

Overview

The Lenovo 42U rack cabinet delivers a 19-inch EIA-310-D compliant mounting environment with adjustable front and rear rails, integrated vertical cable channels, and tool-less PDU mounting options. The cold-rolled steel enclosure is finished in a durable black powder coat, with removable, lockable side panels and a multi-point locking system securing the front, rear, and sides. Heavy-duty casters and leveling feet are included for stable positioning, and an integrated grounding kit ensures proper electrical bonding.

What stands out

• 1000 kg maximum load capacity for dense, heavy equipment configurations
• Offset mounting rails create additional depth for cable management and airflow
• High-airflow perforated doors (front single swing, rear split) with 70% open area
• Multi-point locking system on front, rear, and side panels for physical security
• Tool-less PDU mounting and integrated vertical cable channels simplify installation
• Removable, lockable side panels allow easy access during maintenance
• Heavy-duty casters and leveling feet included for mobility and precise leveling
• Integrated grounding kit included for safe electrical bonding

Technical details

• Rack capacity: 42U
• Rack width: 19-inch standard
• Maximum load capacity: 1000 kg (2200 lbs)
• Material: Cold-rolled steel, powder coated
• Colour: Black
• Front door: Perforated single swing door
• Rear door: Perforated split doors
• Side panels: Removable, lockable
• Mounting rails: Adjustable, front and rear
• Cable management: Integrated vertical cable channels
• PDU mounting: Tool-less options
• Grounding: Integrated grounding kit
• Compliance: EIA-310-D
• Mounting type: Floor standing
• Casters/leveling feet: Heavy-duty, included

Our verdict

For data centers and server rooms that demand both capacity and cooling efficiency, this Lenovo 42U rack cabinet is a robust choice. The offset rails and high-airflow perforation address the challenges of modern high-density equipment, while the 1000 kg load rating and comprehensive locking system provide reliability and security. A solid investment for scalable infrastructure.
