Audio split kabel Equip 147941

The Equip Audio Split Cable (model 147941) provides a single 4-position (CTIA) female 3.5 mm socket and two male 3.5 mm plugs to connect a headset with combined audio and microphone jack to a desktop or laptop with separate audio and mic ports. The compact black cable (0.13 m length, 7 mm thickness) enables connection of headsets, headphones or other 4-position audio devices to computers for online communication and VOIP applications.

Advantages

This audio split cable converts a single 4-position headset connector into separate microphone and headphone plugs, allowing use with PCs and laptops that have distinct audio and mic inputs. Its small size and lightweight construction (0.013 kg) make it convenient for portable setups, and the standard 3.5 mm connectors ensure compatibility with most consumer audio devices.

Suitable for

• Connecting a 4-position headset to a PC or laptop with separate mic and audio jacks
• Online gaming and voice chat applications (VOIP, Skype, Teams)
• Using headphones with microphone on desktop computers

Key specifications

• Brand: EQUIP
• Model / MPN: 147941
• EAN: 4015867204924
• Connectors: 1 x 4-position (female) 3.5 mm; 2 x 3.5 mm (male)
• Cable length: 0.13 m
• Weight: 0.013 kg
• Colour: Black

How to use

Plug the single 4-position female socket into your headset’s combined audio/microphone plug. Insert the two male 3.5 mm plugs into the computer’s microphone and audio output ports respectively. Ensure the plugs are fully seated and select the appropriate input/output devices in your operating system or communication application settings.

Recommendations

Use the cable for indoor computer setups and avoid sharp bends or excessive tension on the cable to maintain connector integrity and audio quality.
